Gesture Module

The Gesture Module uses a combination of machine learning and heuristic methods to provide reliable and accurate gesture detection. With this module, you can detect the following gestures:

  1. Pinches
  2. Palm Tap
  3. Targeting
  4. Grab
  5. Phone in Hand Detection

The Spectacles Interaction Kit utilizes the Gesture Module to build its interactions. While we recommend using the Spectacles Interaction Kit for building experiences, the Gesture Module also allows the creation of a custom interaction system.

Pinch Gesture​

The pinch gesture detects when the thumb and index fingers of the hand in view are pinched together.

Relevant APIs​

Gesture Module Methods​

  • getPinchDownEvent(handType): any

  • getPinchStrengthEvent(handType): any

    • The PinchStrengthArgs provides a normalized value ranging from 0 to 1, where 0 indicates no pinch and 1 indicates a full pinch.

  • getPinchUpEvent(handType): any

Interfaces​

  • interface PinchStrengthArgs { strength: number; }

  • interface PinchUpArgs { palmOrientation: vec3; }

  • interface PinchDownArgs { confidence: number; palmOrientation: vec3; }

Code Example​

@component
export class PinchExample extends BaseScriptComponent {
  private gestureModule: GestureModule = require('LensStudio:GestureModule');
  onAwake() {
    this.gestureModule
      .getPinchDownEvent(GestureModule.HandType.Right)
      .add((pinchDownArgs: PinchDownArgs) => {
        print('Right Hand Pinch Down');
      });

    this.gestureModule
      .getPinchUpEvent(GestureModule.HandType.Right)
      .add((pinchUpArgs: PinchUpArgs) => {
        print('Right Hand Pinch Up');
      });

    this.gestureModule
      .getPinchStrengthEvent(GestureModule.HandType.Right)
      .add((pinchStrengthArgs: PinchStrengthArgs) => {
        print('Right Hand Pinch Strength: ' + pinchStrengthArgs.strength);
      });
  }
}

Palm Tap Gesture​

The palm tap gesture detects when the index finger from one hand touches the palm of the opposite hand. Currently, only the palm tap to the left hand is supported.

Relevant APIs​

Gesture Module Methods​

  • getPalmTapDownEvent(gestureHandType): any

  • getPalmTapUpEvent(gestureHandType): any

Interfaces​

  • interface PalmTapUpArgs { confidence: number; }

  • interface PalmTapDownArgs { confidence: number; }

Code Example​

@component
export class PalmTapExample extends BaseScriptComponent {
  private gestureModule: GestureModule = require('LensStudio:GestureModule');
  onAwake() {
    this.gestureModule
      .getPalmTapUpEvent(GestureModule.HandType.Right)
      .add((palmTapUpArgs: PalmTapUpArgs) => {
        print('Palm tap up event from GestureModule');
      });

    this.gestureModule
      .getPalmTapDownEvent(GestureModule.HandType.Right)
      .add((palmTapDownArgs: PalmTapDownArgs) => {
        print('Palm tap down event from GestureModule');
      });
  }
}

Targeting Gesture​

The targeting gesture is detected when the user has an intent to target a digital content in space.

Relevant APIs​

Gesture Module Methods​

  • getTargetingDataEvent(gestureHandType): any
    • This method triggers every frame to provide targeting data based on the specified gestureHandType.

Interfaces​

  • interface TargetingDataArgs { isValid: boolean; rayDirectionInWorld: vec3; rayOriginInWorld: vec3; }
    • When isValid is false, rayDirectionInWorld and rayOriginInWorld return the last calculated values.

Code Example​

@component
export class TargetingExample extends BaseScriptComponent {
  private gestureModule: GestureModule = require('LensStudio:GestureModule');
  onAwake() {
    this.gestureModule
      .getTargetingDataEvent(GestureModule.HandType.Right)
      .add((targetArgs: TargetingDataArgs) => {
        print('Is Valid: ' + targetArgs.isValid);
        print('Ray Origin In World: ' + targetArgs.rayOriginInWorld);
        print('Ray Direction In World: ' + targetArgs.rayDirectionInWorld);
      });
  }
}

Grab Gesture​

The grab gesture detects when the hand performs a grab pose, enabling interactions such as grabbing virtual objects or making a fist.

Relevant APIs​

Gesture Module Methods​

  • getGrabBeginEvent(handType): any

  • getGrabEndEvent(handType): any

Interfaces​

  • interface GrabBeginArgs { }

  • interface GrabEndArgs { }

Code Example​

@component
export class GrabExample extends BaseScriptComponent {
  private gestureModule: GestureModule = require('LensStudio:GestureModule');
  onAwake() {
    this.gestureModule
      .getGrabBeginEvent(GestureModule.HandType.Right)
      .add((grabBeginArgs: GrabBeginArgs) => {
        print('Right Hand Grab Begin');
      });
  }
}

Phone in Hand Detection​

The IsPhoneInHand events indicate whether a tracked hand is holding a phone-like object. Note: Only objects with a smartphone-like appearance are detected.

Relevant APIs​

Gesture Module Methods​

  • getIsPhoneInHandBeginEvent(handType): any

  • getIsPhoneInHandEndEvent(handType): any

Interfaces​

  • interface IsPhoneInHandBeginArgs { }

  • interface IsPhoneInHandEndArgs { }

Code Example​

@component
export class IsPhoneInHandExample extends BaseScriptComponent {
  private gestureModule: GestureModule = require('LensStudio:GestureModule');
  onAwake() {
    this.gestureModule
      .getIsPhoneInHandBeginEvent(GestureModule.HandType.Right)
      .add((grabBeginArgs: GrabBeginArgs) => {
        print('Right hand started to hold a phone.');
      });
  }
}
