Camera Controller

A modular and customizable system for managing camera behavior. This component includes multiple presets such as third-person, follow, orbit, and gyroscope modes, allowing developers to fine-tune camera positioning, movement, and responsiveness for a wide range of gaming experiences and interactive Lens formats.

Key Features

The Camera Controller component provides four distinct camera behaviors:

1. Follow Mode - Camera tracks a target object's position with optional axis locking
2. Third-Person Mode - Automatically follows a character and rotates toward character direction
3. Orbit Mode - Allows free rotation around a target with touch controls
4. Gyroscope Mode - Uses device orientation to rotate the camera around a pivot relative to the target

Usage

1. Locate the Camera Controller custom component in the Asset Library.
2. Click the Install button to add it to your project. Once installed, the component can be attached to a Scene Object.
3. Set the Camera Input to the Camera Object you want to control and select the Camera Mode you wish to use.
4. Set the Follow Target to the Scene Object you want the Camera to track.
5. Customize the camera behavior by adjusting the Smoothing Factor, Offset and Lock Axis settings.

Camera Modes

Follow Mode

The camera tracks the Follow Target's position while maintaining its current orientation. Ideal for side-scrolling games or situations where you want the camera to move but not rotate.

Features:

• Tracks target position only
• Maintains camera's original rotation
• Supports axis locking for 2D-style movement
• Configurable smoothing for natural movement

Third Person Mode

Automatically follows a character and rotates toward the character's direction. Perfect for third-person adventure games, character showcases, and exploration experiences.

Features:

• Follows target position and rotation
• Maintains consistent distance from target
• Smooth interpolation for natural camera movement
• Works seamlessly with Character Controller component

Usage with Character Controller: To use Third Person Mode with a character, attach the Camera Controller component to your camera and set the Follow Target to the Scene Object that has the Character Controller component attached. The camera will automatically follow the character's movement and rotate to face the direction the character is moving.

Camera Placement: When using Third Person Mode, make sure to position your camera behind the character in the scene. The camera will maintain this relative position and distance as it follows the character.

Orbit Mode

Allows free rotation around a target using touch controls. Users can tap and drag within a specified Interactive Area to orbit the camera around the Follow Target, ideal for interactive 3D object viewers and third person games.

Features:

• Touch-controlled camera rotation
• Configurable interaction area
• Automatic orbit option for hands-free rotation
• Vertical and horizontal rotation clamping
• Adjustable orbit speed

Gyroscope Mode

Uses the device's orientation to rotate the camera around a pivot positioned relative to the Follow Target. Ideal for device-tilt controls, first/third-person exploration, and immersive object/viewer experiences.

Features:

• Device-orientation-driven camera rotation (roll, pitch, yaw)
• Selectable active axes: Roll, Pitch, Yaw
• Calibration helpers

• Use calibrateToCurrentDevice() to set the current device orientation as the zero reference.
• Or call calibrateYaw(), calibratePitch(), or calibrateRoll() to adjust specific axes during gameplay.

---

Camera Mode Selection:

• Use Follow for side-scrolling or platform games
• Use Third Person for character-based adventure games
• Use Orbit for interactive 3D showcases and object viewers
• Use Gyroscope for device-tilt driven interactions and immersive exploration

Obstacle Avoidance

Camera Controller includes built-in obstacle avoidance to make sure the camera has a clear line of sight to the Follow Target. If an obstacle is detected between the camera and the target, the camera will adjust its position to move closer to the target, preventing clipping through objects.

Character Collider: Make sure to add your Character Controller to the Character To Ignore input of the Camera Controller to prevent the camera from colliding with the character itself.

Obstacle avoidance uses raycasting to detect obstacles. Make sure that the objects you want the camera to avoid have appropriate colliders (Physics Collider or Physics Body, non-intangible). Add any collider you want the camera to ignore to the Colliders To Ignore array in the Camera Controller component.

You can debug obstacle avoidance by checking the Enable Debug option in Obstacle Avoidance section of the Camera Controller component. This example shows the raycast used for obstacle detection (using a different camera for clarity):

Component Inputs

Name	Type	Description
Camera	SceneObject or null	The camera object this script will control.
Follow Target	SceneObject or null	Scene Object that the camera will track / follow.
Snap To Target On Awake	boolean	If enabled, the camera will immediately snap to the target location when the CameraController awakens.
Camera Mode	string	Initial camera mode. One of "Orbit", "Third Person", "Follow", "Gyroscope".
Print Warning Logs	boolean	If true, warning logs will be printed.
Print Info Logs	boolean	If true, info logs will be printed.
Orbit Mode
Smoothing Factor	number	Controls how smoothly the camera follows its target (higher = smoother), min 0 – max 1.
Radius	number	Distance from target to camera.
Pivot Offset	vec3	Offset relative to the Follow Target's transform that positions the orbit pivot (the point the camera orbits around) in the target's local space.
Orbit Speed	number	Controls how fast the camera rotates around the target. The sign of the speed defines the direction of auto-orbit movement.
Auto Orbit	boolean	If enabled, the camera will continuously orbit around the target.
Vertical Clamp	vec3	Limits how far up/down the camera can rotate. Format: (min, max, default).
Horizontal Clamp	vec3	Limits how far left/right the camera can rotate. Format: (min, max, default).
Interactive Area	InteractionComponent	Touchable screen region for swipe/gesture control. If null, the whole screen is interactive.
Third Person Mode
Smoothing Factor	number	Controls how smoothly the camera follows its target (higher = smoother), min 0 – max 1.
Use Scene Derived Offset	boolean	If enabled, automatically derives the camera's relative position & rotation offset from the current scene setup.
Position Offset	vec3	Position offset from target. Applicable if Use Scene Derived Offset is disabled.
Rotation Offset	vec3	Additional rotation offset. Applicable if Use Scene Derived Offset is disabled.
Follow Mode
Smoothing Factor	number	Controls how smoothly the camera follows its target (higher = smoother), min 0 – max 1.
Use Scene Derived Offset	boolean	If enabled, automatically derives the camera's relative position offset from the current scene setup.
Position Offset	vec3	Offset from target. Applicable if Use Scene Derived Offset is disabled.
Lock X	boolean	Restricts the camera from moving or rotating along the X axis.
Lock Y	boolean	Restricts the camera from moving or rotating along the Y axis.
Lock Z	boolean	Restricts the camera from moving or rotating along the Z axis.
Gyroscope Mode
Smoothing Factor	number	Controls smoothing of the pivot/position movement (higher = smoother). Does not smooth device rotation. Min 0 – max 1.
Pivot Position	vec3	Offset relative to the target transform used to place the rotation pivot.
Pivot Rotation	vec3	Extra Euler rotation (degrees) applied at the pivot before device rotation.
Position Offset	vec3	Camera position offset from the pivot, applied after pivot and device rotation.
Active Axes	enum	Which device axes affect camera rotation. One of: All, Roll, Pitch, Yaw, RollPitch, RollYaw, PitchYaw.
Obstacle Avoidance
Avoid Obstacles	boolean	If enabled, the camera will avoid obstacles between itself and the Follow Target.
Check Radius	number	Radius of the raycast sphere used during obstacle avoidance checks (higher = larger area checked for obstacles)
Origin Offset	vec3	Offset relative to the target transform (position, scale, rotation) to start the raycast from
Character To Ignore	ScriptComponent	The Character Controller to ignore its collider during obstacle avoidance checks
Colliders To Ignore	ColliderComponent[]	Additional colliders to ignore during obstacle avoidance checks
Return Smoothing Factor	number	Controls how quickly the camera moves back to its desired position after avoiding an obstacle (higher = faster), min value - 0, max value - 1
Minimum Distance Factor	number	Minimum distance to maintain from the target when avoiding obstacles (higher = further away), min value - 0, max value - 1
Enable Debug	boolean	Enables debug drawing of the obstacle avoidance raycast checks

Component API

Name (signature)	Description
camera: SceneObject | null	Gets/sets the SceneObject the component drives.
followTarget: SceneObject | null	Gets/sets the SceneObject the camera follows.
cameraMode: CameraMode	Returns the currently active camera mode.
enableFollowCameraMode(): FollowCameraModeStrategy	Switches the component to Follow mode and returns the strategy object for runtime modifications.
enableThirdPersonCameraMode(): ThirdPersonCameraModeStrategy	Switches the component to Third Person mode and returns the strategy object for runtime modifications.
enableOrbitCameraMode(): OrbitCameraModeStrategy	Switches the component to Orbit mode and returns the strategy object for runtime modifications.
enableGyroscopeCameraMode(): GyroscopeCameraModeStrategy	Switches the component to Gyroscope mode and returns the strategy object for runtime modifications.
getCameraModeStrategy(): CameraModeStrategy | null	Gets the currently active camera mode strategy object. You can cast this to a specific type (e.g., OrbitCameraModeStrategy) to modify it.
moveToTarget(): void	Instantly moves the camera to its final position (without smoothing). It is useful after switching modes.
getObstacleAvoidance(): ObstacleAvoidance	Returns the current ObstacleAvoidance instance, which can be used to tweak obstacle avoidance settings.
setObstacleAvoidance(obstacleAvoidance: ObstacleAvoidance): void	Sets a new ObstacleAvoidance instance.
isObstacleAvoidanceEnabled(): boolean	Returns true if obstacle avoidance is enabled
enableObstacleAvoidance(): void	Enables obstacle avoidance by moving the camera closer to the target when obstacles are detected.
disableObstacleAvoidance(): void	Disables obstacle avoidance. The camera will not adjust its position when obstacles are detected.
printWarningLogs: boolean	Gets/sets the flag for printing warning logs.
printInfoLogs: boolean	Gets/sets the flag for printing info logs.

Mode-specific API

The enable...CameraMode() methods return a strategy object when a mode is activated. You can also get the currently active strategy object at any time by calling getCameraModeStrategy(). This object allows you to modify the mode's properties at runtime.

Follow Mode (FollowCameraModeStrategy)

Name	Type	Description
smoothingFactor	number	Controls how smoothly the camera follows its target (0-1, higher = smoother).
positionOffset	vec3	Local-space offset applied to the camera position.
lockX	boolean	Restricts the camera from moving / rotating along world X axis.
lockY	boolean	Restricts the camera from moving / rotating along world Y axis.
lockZ	boolean	Restricts the camera from moving / rotating along world Z axis.

Third Person Mode (ThirdPersonCameraModeStrategy)

Name	Type	Description
smoothingFactor	number	Controls how smoothly the camera follows its target (0-1, higher = smoother).
positionOffset	vec3	Local-space offset applied to the camera position.
rotationOffset	quat	Additional rotation applied to the camera as a quaternion.

Orbit Mode (OrbitCameraModeStrategy)

Name	Type	Description
smoothingFactor	number	Controls how smoothly the camera follows its target (0-1, higher = smoother).
radius	number	Distance from target to camera.
pivotOffset	vec3	Offset relative to the Follow Target's transform that positions the orbit pivot in the target's local space.
orbitSpeed	number	Controls how fast the camera orbits around the target.
autoOrbit	boolean	If enabled, the camera will continuously orbit around the target.
verticalClamp	vec3	Limits how far up/down the camera can rotate. Format: (min, max, default).
horizontalClamp	vec3	Limits how far left/right the camera can rotate. Format: (min, max, default).
interactiveArea	InteractionComponent	Touchable screen region for swipe / gesture-based control.

Gyroscope Mode (GyroscopeCameraModeStrategy)

Properties

Name	Type	Description
smoothingFactor	number	Controls pivot/position smoothing applied to target. Does not smooth device rotation.
pivotPosition	vec3	Pivot offset relative to the target.
pivotRotation	quat	Additional pivot rotation. In the inspector you can enter Euler degrees; at runtime it's a quaternion.
positionOffset	vec3	Camera offset applied after pivot and device rotation.
activeAxes	enum	Which device axes are applied to rotation. One of: All, Roll, Pitch, Yaw, RollPitch, RollYaw, PitchYaw.
zeroRotation	quat	Calibration reference treated as identity. Incoming device rotation R is calibrated as Z^-1 · R (Z is zeroRotation), then filtered by activeAxes. Not smoothed.

Methods

Signature	Description
calibrateToCurrentDevice(): void	Set current device orientation as zero.
calibrateYaw(): void	Calibrate yaw only.
calibratePitch(): void	Calibrate pitch only.
calibrateRoll(): void	Calibrate roll only.

Obstacle Avoidance API

Obstacle avoidance can be configured at runtime using the ObstacleAvoidance instance returned by calling getObstacleAvoidance().

Name (signature)	Description
calculatePosition(targetTransform: Transform, desiredCameraPosition: vec3): vec3	Calculates a new camera position to avoid obstacles between the target and desired camera position. Returns the adjusted camera position.
getCheckRadius(): number	Returns the radius used for the RayCast obstacle checks.
setCheckRadius(radius: number): void	Sets the new radius for the RayCast obstacle checks.
getOriginOffset(): vec3	Returns the offset from the target used as the origin for the RayCast obstacle checks. Relative to the target's transform.
setOriginOffset(offset: vec3): void	Sets the new offset from the target for the RayCast obstacle checks. Relative to the target's transform.
getCharacterToIgnore(): ScriptComponent | null	Returns the Character Controller script to ignore during obstacle checks or null if none is set.
setCharacterToIgnore(character: ScriptComponent | null): void	Sets the Character Controller script to ignore during obstacle checks or null to clear the current setting.
getCollidersToIgnore(): ColliderComponent[]	Returns the colliders to ignore during obstacle checks.
setCollidersToIgnore(colliders: ColliderComponent[]): void	Sets the colliders to ignore during obstacle checks.
getReturnSmoothingFactor(): number	Returns the smoothing factor for returning the camera to the desired position if obstacles are no longer detected.
setReturnSmoothingFactor(factor: number): void	Sets the new smoothing factor for returning the camera to the desired position if obstacles are no longer detected.
getMinDistanceFactor(): number	Returns the minimum distance factor from the target when avoiding obstacles. 0 means the camera can be at the target position, 1 means the camera cannot move from its desired position.
setMinDistanceFactor(factor: number): void	Sets the new minimum distance factor from the target when avoiding obstacles. 0 means the camera can be at the target position, 1 means the camera cannot move from its desired position.
enableDebug(): void	Enable debug mode for showing the RayCast probe in the scene.
disableDebug(): void	Disable debug mode for hiding the RayCast probe in the scene.

Testing on Device

To preview your Lens in Snapchat, follow the Pairing to Snapchat guide.
