Beat Sync

The Beat Sync Custom Component enables creators to build real-time, beat-responsive effects in Lens Studio by leveraging the Sound Sync API. It offers customizable response events triggered by musical beats (e.g., downbeats, specific beat indices) and allows creators to control visuals, animations, materials, and logic in perfect sync with a selected music track.

How Beat Sync Works

The Beat Sync component uses beat data from the Sound Sync API to trigger synchronized responses:

1. Beat Data Loading - The component loads pre-analyzed beat data for the selected music track from the Asset Library
2. Trigger Detection - Based on configured triggers (OnBeat, OnDownBeat, or specific beat indices), events are fired at precise timestamps
3. Response Execution - When triggers activate, various responses can be executed including behavior scripts, custom API calls, or property modifications
4. Synchronized Effects - Visual effects, animations, and other behaviors stay perfectly in sync with the music using the pre-computed beat timestamps

Common use cases include:

• Music Visualizers - Creating visual effects that pulse with the beat
• Rhythm Games - Triggering gameplay events on specific beats
• Dance Experiences - Synchronizing character animations with music
• Video Templates - Coordinating scene changes and transitions with audio

Installing the Component

The Beat Sync custom component is available in the Lens Studio Asset Library. Press Install or Update and then add it to the Asset Browser panel by clicking the + button and looking up Beat Sync.

Downloading Music Tracks

To use the Beat Sync component, you must download music tracks from the Asset Library:

1. Find Music Tracks - Go to the Asset Library and navigate to the Music section
2. Select a Track - Choose a music track that will be used in your lens
3. Mark as Unbundled - Make sure to uncheck the Bundled option for the selected track. This allows users to change the track in your lens on their own, and the component will not work if this option is enabled

Beat Sync can not be used in sponsored Lenses. Learn more in the Music on Snapchat Guidelines.

Basic Setup

1. Add to Scene - Drag the Beat Sync component to a scene object
2. Set Audio Track - Assign the downloaded Audio Track to load beat data from
3. Configure Triggers - Set up trigger inputs to define when events should occur
4. Add Responses - Configure responses for each trigger (behaviors, scripts, or property changes)

Component Inputs

Core Settings

Input	Type	Description
Audio Track	AudioTrackAsset	The audio file that will be used for beat synchronization
Triggers Input	TriggerInput[]	An array of trigger inputs that define when and how events should occur based on the beat
Print Warns	Boolean	If set to true, it will print warnings to the console for debugging purposes (defaults to false)

Trigger Input Configuration

Each Trigger Input defines a specific point in the music and the actions that should be taken:

Input	Type	Description
Trigger Type	Enum	Determines the type of beat that will trigger the response: • OnBeat - Any beat • OnDownBeat - The first beat of a measure • OnBeatIndex - A specific beat number
Beat Index	Number	If Trigger Type is OnBeatIndex, specifies the exact beat number (from 1 to 64)
Responses	ResponseInput[]	Array of responses that will be executed when the trigger condition is met

Response Configuration

Each Response Input specifies the action to be taken when a trigger is fired:

Input	Type	Description
Response Type	Enum	The typea of action to perform: • Behavior Script - Trigger a behavior script • Custom Script API Method - Call a custom script method • Expose Property - Modify a property value over time

Behavior Response Input

For triggering behavior scripts:

Input	Type	Description
Behavior Trigger Type	Enum	Method for triggering the behavior: • Global CustomTrigger - Use a custom trigger name • Manual Trigger - Direct reference to script component
Custom Trigger Name	String	Name of the custom trigger (for Global CustomTrigger)
Behavior Script	ScriptComponent	Direct reference to script component (for Manual Trigger)

Script API Response Input

For calling custom script methods:

Input	Type	Description
Script	ScriptComponent	Reference to the script component containing the method
Method Name	String	Name of the method to be called on the script
Response Type	Enum	How the script responds: • Only Trigger - Simple trigger with no value • Fading Value - Value that changes over time
Fading Value Input	FadingValueInput	Fading transition properties (if using Fading Value)

Expose Property Response Input

For controlling property values:

Input	Type	Description
Exposed Property Name	String	Name of the property to be exposed and modified
Fading Value Input	FadingValueInput	Defines the fading behavior for the exposed property

Fading Transition Input

Defines how values change over time:

Input	Type	Description
Fading Type	Enum	Type of fading transition: • Linear - Constant rate of change • Logarithmic - Creates ease-in or ease-out effect • FixedStep - Incremental value changes
Fading Speed	Number	Controls the rate of transition (behavior depends on Fading Type)
Fixed Step Size	Number	Incremental value change for each step (FixedStep only)

Previewing Your Lens

To preview your Beat Sync Lens in Snapchat, follow the Pairing to Snapchat guide. A helpful testing flow to follow is:

1. Push the lens to your device to test audio playback and beat synchronization
2. Test with different music tracks to verify beat sync accuracy
3. Verify trigger timing matches expected beat patterns
4. Check response effects activate at the correct moments
5. Test performance with multiple simultaneous effects
